Productos del fabricanteHC-49/US/3 leads

Buscar diseño de referencia (fabricante de CI)

Nuestra lista de referencias le indica con qué circuitos integrados, entre otros, pueden utilizarse nuestros cristales. Por supuesto, para la sincronización de otros circuitos integrados, disponemos de cristales adecuados, con una resistencia muy baja para una oscilación muy rápida y fiable, de nuestra gama de productos especialmente amplia y profunda. Para nuevos desarrollos, recomendamos cristales MHz de las series SMD03025/4 (3,2x2,5mm/4pad) o SMD2016/4 (2,0x1,6/4mm). El cristal SMD de la serie SMD03025/4 es actualmente el cristal SMD miniaturizado más barato y el cristal SMD de la serie SMD02016/4 se utiliza en aplicaciones para las que el SMD03025/4 es demasiado grande. También recomendamos los siguientes cristales oscilantes SMD: SMD02016/4US y SMD03025/4US para el proceso de sellado por ultrasonidos.

Fabricante CI Package Frecuencia CL ESR Numero del producto Ficha técnica Muestra Producto
Infineon TDA5240 5.0 x 3.2 mm 21.948717 MHz 12 pF 60 Ω SMD0503/4 21.948717 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
Infineon TDA5235 5.0 x 3.2 mm 21.948717 MHz 12 pF 60 Ω SMD0503/4 21.948717 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
Infineon TDA5225 5.0 x 3.2 mm 21.948717 MHz 12 pF 60 Ω SMD0503/4 21.948717 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 12 pF 25 Ω SMD02016/4 50.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 12 pF 25 Ω SMD02016/4 50.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
NXP RT600 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
NXP RT600 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP RT600 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP RT600 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
NXP RT600 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
NXP RT600 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
NXP QN908x 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
NXP QN908x 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP QN908x 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP QN908x 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
NXP QN908x 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
NXP QN908x 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
NXP QN908x 3.2 x 1.5 mm 32.768 kHz 6pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)
PDF
Solicitud Consultas
NXP QN908x 3.2 x 1.5 mm 32.768 kHz 7 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
NXP QN908x 3.2 x 1.5 mm 32.768 kHz 9pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)
PDF
Solicitud Consultas
NXP QN9090 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
NXP QN9090 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP QN9090 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP QN9090 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
NXP QN9090 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
NXP QN9090 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
NXP QN9090 3.2 x 1.5 mm 32.768 kHz 6pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)
PDF
Solicitud Consultas
NXP QN9030 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
NXP QN9030 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP QN9030 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP QN9030 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
NXP QN9030 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
NXP QN9030 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
NXP QN9030 3.2 x 1.5 mm 32.768 kHz 6pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)
PDF
Solicitud Consultas
NXP NHS52S04 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
NXP NHS52S04 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP NHS52S04 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
NXP NHS52S04 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
NXP NHS52S04 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
NXP NHS52S04 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
NXP NHS52S04 3.2 x 1.5 mm 32.768 kHz 6pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)
PDF
Solicitud Consultas
NXP NHS52S04 3.2 x 1.5 mm 32.768 kHz 7 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
NXP NHS52S04 3.2 x 1.5 mm 32.768 kHz 9pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC1310 1.6 x 1.2 mm 24.000 MHz 8 pF 70 Ω SMD01612/4 24.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC1310 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC1310 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC1310 1.6 x 1.0 mm 32.768 kHz 7 pF 90 kΩ M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC1310 3.2 x 1.5 mm 32.768 kHz 7 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC23xx 1.6 x 1.0 mm 32.768 kHz 7 pF 90 kΩ M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC23xx 3.2 x 1.5 mm 32.768 kHz 7 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC26xx 1.6 x 1.0 mm 32.768 kHz 7 pF 90 kΩ M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC26xx 3.2 x 1.5 mm 32.768 kHz 7 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Texas Instruments CC26xx 2.0 x 1.6 mm 48.000 MHz 7 pF 20 Ω SMD02016/4 48.000 MHz 10/20/-40+85/7pF
PDF
Solicitud Consultas
Texas Instruments CC2652R 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Texas Instruments CC2652R 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC2652R 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC2652R 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Texas Instruments CC2652R 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC2652R 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC13xx 2.0 x 1.6 mm 48.000 MHz 7 pF 20 Ω SMD02016/4 48.000 MHz 10/20/-40+85/7pF
PDF
Solicitud Consultas
Texas Instruments CC2642R 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC2642R 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Texas Instruments CC2642R 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC2642R 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Texas Instruments CC2642R 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Texas Instruments CC2642R 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Qualcomm Snapdragon 2.0 x 1.6 mm 48.000 MHz 8.8 pF 20 Ω SMD02016/4 48.000 MHZ 10/15/-40+85/8.8PF
PDF
Solicitud Consultas
Nordic nRF51822 3.2 x 1.5 mm 32.768 kHz 9pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)
PDF
Solicitud Consultas
Nordic nRF51822 3.2 x 1.5 mm 32.768 kHz 12.5 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 12.5pF (-40/+85°C)
PDF
Solicitud Consultas
Nordic nRF51822 2.0 x 1.6 mm 16.000 MHz 8 pF 150 Ω SMD02016/4 16.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF51822 2.0 x 1.6 mm 16.000 MHz 10 pF 150 Ω SMD02016/4 16.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Nordic nRF51822 2.0 x 1.6 mm 16.000 MHz 12 pF 150 Ω SMD02016/4 16.000 MHz 10/20/-40+85/12pF
-
 Solicitud Consultas
Nordic nRF51822 2.0 x 1.6 mm 32.000 MHz 8 pF 60 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF51822 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF51822 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Nordic nRF52 2.0 x 1.6 mm 32.000 MHz 8 pF SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Nordic nRF53 2.0 x 1.6 mm 32.000 MHz 8 pF SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52832 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Nordic nRF52832 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF52832 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF52832 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52832 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52832 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52811 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52811 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52811 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Nordic nRF52811 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF52811 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF52811 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Nordic nRF51822 2.0 x 1.6 mm 32.000 MHz 10 pF 60 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Nordic nRF5340 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Nordic nRF5340 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Nordic nRF5340 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Nordic nRF5340 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF5340 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Nordic nRF5340 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Silicon Labs EFR32BG21 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32BG21 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32BG21 2.0 x 1.6 mm 38.400 MHz 10 pF 55 Ω SMD02016/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32MG21 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32MG21 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32MG21 2.0 x 1.6 mm 38.400 MHz 10 pF 55 Ω SMD02016/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32MG22 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32MG22 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32MG22 2.0 x 1.6 mm 38.400 MHz 10 pF 55 Ω SMD02016/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32FG22 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32FG22 3.2 x 2.5 mm 38.400 MHz 10 pF 35 Ω SMD03025/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Silicon Labs EFR32FG22 2.0 x 1.6 mm 38.400 MHz 10 pF 55 Ω SMD02016/4 38.400 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Decawave DW1000 2.0 x 1.6 mm 38.400 MHz 8 pF 50 Ω SMD02016/4 38.400 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Decawave DW1000 2.0 x 1.6 mm 38.400 MHz 8 pF 50 Ω SMD02016/4 38.400 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Decawave DW1000 2.0 x 1.6 mm 38.400 MHz 8 pF 50 Ω SMD02016/4 38.400 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Decawave DW1000 3.2 x 2.5 mm 38.400 MHz 8 pF 35 Ω SMD03025/4 38.400 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Decawave DW1000 3.2 x 2.5 mm 38.400 MHz 8 pF 35 Ω SMD03025/4 38.400 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Decawave DW1000 3.2 x 2.5 mm 38.400 MHz 8 pF 35 Ω SMD03025/4 38.400 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Solicitud Consultas
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Solicitud Consultas
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Solicitud Consultas
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Solicitud Consultas
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Solicitud Consultas
Renesas DA14585 3.2 x 2.5 mm 16.000 MHz 12 pF 85 Ω SMD03025/4 16.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
Renesas DA14585 3.2 x 1.5 mm 32.768 kHz 6pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)
PDF
Solicitud Consultas
Renesas DA14585 3.2 x 1.5 mm 32.768 kHz 7 pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Renesas DA14585 3.2 x 1.5 mm 32.768 kHz 9pF 50 kΩ M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)
PDF
Solicitud Consultas
Renesas DA14585 1.6 x 1.0 mm 32.768 kHz 6pF 90 kΩ M1610 32.768 kHz ±20 ppm 6pF (-40/+85°C)
PDF
Solicitud Consultas
Renesas DA14585 1.6 x 1.0 mm 32.768 kHz 7 pF 90 kΩ M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)
PDF
Solicitud Consultas
Renesas DA14585 1.6 x 1.0 mm 32.768 kHz 9pF 90 kΩ M1610 32.768 kHz ±20 ppm 9pF (-40/+85°C)
PDF
Solicitud Consultas
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/50/-40+125/10pF/AUT
PDF
Solicitud Consultas
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/50/-40+125/10pF/AUT
PDF
Solicitud Consultas
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/15/-40+85/10pF
PDF
Solicitud Consultas
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/10/-20+70/10pF
PDF
Solicitud Consultas
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/50/-40+125/10pF/AUT
PDF
Solicitud Consultas
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/20/-40+85/10pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 8 pF 30 Ω SMD02016/4 50.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 12 pF 30 Ω SMD02016/4 50.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 8 pF 30 Ω SMD02016/4 50.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 8 pF 30 Ω SMD02016/4 50.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 8 pF 80 Ω SMD02016/4 25.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 12 pF 30 Ω SMD03025/4 24.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 25.000 MHz 8 pF 30 Ω SMD03025/4 25.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 25.000 MHz 8 pF 30 Ω SMD03025/4 25.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 12 pF 25 Ω SMD03025/4 50.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 8 pF 25 Ω SMD03025/4 50.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 8 pF 25 Ω SMD03025/4 50.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 8 pF 25 Ω SMD03025/4 50.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 8 pF 30 Ω SMD03025/4 26.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 8 pF 30 Ω SMD03025/4 26.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 12 pF 30 Ω SMD03025/4 26.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 8 pF 30 Ω SMD03025/4 26.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 12 pF 30 Ω SMD03025/4 26.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 12 pF 25 Ω SMD03025/4 48.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 12 pF 25 Ω SMD03025/4 48.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 12 pF 25 Ω SMD03025/4 48.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 8 pF 80 Ω SMD02016/4 25.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
STM STM8AF/AL/S 5.0 x 3.2 mm 8.000 MHz 12 pF 150 Ω SMD0503/4 8.000 MHz 10/10/-20+70/12pF/150R/500µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 5.0 x 3.2 mm 8.000 MHz 12 pF 150 Ω SMD0503/4 8.000 MHz 10/15/-40+85/12pF/150R/500µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 5.0 x 3.2 mm 8.000 MHz 12 pF 150 Ω SMD0503/4 8.000 MHz 10/20/-40+85/12pF/150R/500µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 400 Ω SMD03025/4 8.000 MHz 10/10/-20+70/12pF/400R/200µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 500 Ω SMD03025/4 8.000 MHz 10/10/-20+70/12pF/500R/500µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 400 Ω SMD03025/4 8.000 MHz 10/20/-40+85/12pF/400R/200µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 500 Ω SMD03025/4 8.000 MHz 10/15/-40+85/12pF/500R/500µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 400 Ω SMD03025/4 8.000 MHz 10/15/-40+85/12pF/400R/200µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 500 Ω SMD03025/4 8.000 MHz 10/20/-40+85/12pF/500R/500µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 16.000 MHz 12 pF 50 Ω SMD03025/4 16.000 MHz 10/10/-20+70/12pF/50R/300µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 16.000 MHz 12 pF 50 Ω SMD03025/4 16.000 MHz 10/15/-40+85/12pF/50R/300µW
PDF
Solicitud Consultas
STM STM8AF/AL/S 3.2 x 2.5 mm 16.000 MHz 12 pF 50 Ω SMD03025/4 16.000 MHz 10/20/-40+85/12pF/50R/300µW
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 8 pF 25 Ω SMD02016/4 50.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 12 pF 25 Ω SMD02016/4 50.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 8 pF 25 Ω SMD02016/4 50.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 8 pF 25 Ω SMD02016/4 50.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/12pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/8pF
PDF
Solicitud Consultas
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/12pF
PDF
Solicitud Consultas
Llámanos

+49 / 81 91 / 30 53 95

Llámanos

Utilice nuestro formulario de contacto

Llámanos

Envíenos un correo electrónico

Puede enviarnos un correo electrónico en cualquier momento a

info@petermann-technik.de

Llámanos

Solicitud de muestras

Cristal resonante SMD3225 12,0 - 80,0 MHz

Con sólo unos clics, puede solicitar inmediatamente muestras de cualquier producto que desee
